GLIM-2 Wallwasher

Efficacy

133-180 lm/W

CRI

IP66

Warranty

5 years

Techlumen© GLIM-2 linear LED fixtures are ideal for architectural wall-washing and façade lighting.

They feature IP66 protection and excellent mechanical strength. Made of anodized aluminium, they are designed for use in demanding or coastal environments.

Lightweight and slim, the GLIM-2 fixtures achieve up to 155 lm/W and luminous flux up to 23 400 lm.

Available in CCT versions from 2000 K (warm) to 5000 K (cool). They are easily mounted using their snap-fit bracket system for quick installation.

GLIM-2 luminaires come with a 5-year warranty and L80 > 80 000 h rated lifetime.

Applications:
Façades · Monuments · Hotels · Museums · Commercial buildings · Indoor architectural elements

✉️ Request Quote Download PDF

📐

Calculate Required Luminaires

Via Techlumen Lux Calculator

📄

Luminaire Brochure

Detailed specifications

🔧

Installation Manual

Mounting and wiring instructions

📊

Photometric Files

LDT / IES for lighting design

Technical Specifications

Luminous Flux 1272 - 13600 lm

Power 26 - 152W

Efficacy 133 - 180 lm/W

CRI 80

CCT 2000K-5000K

IP Rating IP66

Dimensions 76mm x 76mm x (200 - 1000)mm

Weight 6.5 kg

Warranty 5 years

Certifications & Compliance

EN 60598-1:2021+A11:2022 ROHS EN 60598-1 EN 61000-3 EN 61547 EN 55015 EN 62471 EN 62493 EN 63000

Available Versions

Power	Code	CCT	CRI	Lumen	Efficacy
32W	GLIM-2-a-32-820-17	2000K	80	1,760 lm	104 lm/W
32W	GLIM-2-a-32-827-17	2700K	80	2,240 lm	133 lm/W
32W	GLIM-2-a-32-830-17	3000K	80	2,400 lm	143 lm/W
32W	GLIM-2-a-32-840-17	4000K	80	2,560 lm	152 lm/W
32W	GLIM-2-a-32-850-17	5000K	80	2,600 lm	155 lm/W
45W	GLIM-2-a-45-820-25	2000K	80	2,640 lm	104 lm/W
45W	GLIM-2-a-45-827-25	2700K	80	3,360 lm	133 lm/W
45W	GLIM-2-a-45-830-25	3000K	80	3,600 lm	143 lm/W
45W	GLIM-2-a-45-840-25	4000K	80	3,840 lm	152 lm/W
45W	GLIM-2-a-45-850-25	5000K	80	3,900 lm	155 lm/W
60W	GLIM-2-a-60-820-34	2000K	80	3,520 lm	104 lm/W
60W	GLIM-2-a-60-827-34	2700K	80	4,480 lm	133 lm/W
60W	GLIM-2-a-60-830-34	3000K	80	4,800 lm	143 lm/W
60W	GLIM-2-a-60-840-34	4000K	80	5,120 lm	152 lm/W
60W	GLIM-2-a-60-850-34	5000K	80	5,200 lm	155 lm/W
75W	GLIM-2-a-75-820-42	2000K	80	4,400 lm	104 lm/W
75W	GLIM-2-a-75-827-42	2700K	80	5,600 lm	133 lm/W
75W	GLIM-2-a-75-830-42	3000K	80	6,000 lm	143 lm/W
75W	GLIM-2-a-75-840-42	4000K	80	6,400 lm	152 lm/W
75W	GLIM-2-a-75-850-42	5000K	80	6,500 lm	155 lm/W
90W	GLIM-2-a-90-820-50	2000K	80	5,280 lm	104 lm/W
90W	GLIM-2-a-90-827-50	2700K	80	6,720 lm	133 lm/W
90W	GLIM-2-a-90-830-50	3000K	80	7,200 lm	143 lm/W
90W	GLIM-2-a-90-840-50	4000K	80	7,680 lm	152 lm/W
90W	GLIM-2-a-90-850-50	5000K	80	7,800 lm	155 lm/W
105W	GLIM-2-a-105-820-60	2000K	80	6,160 lm	104 lm/W
105W	GLIM-2-a-105-827-60	2700K	80	7,840 lm	133 lm/W
105W	GLIM-2-a-105-830-60	3000K	80	8,400 lm	143 lm/W
105W	GLIM-2-a-105-840-60	4000K	80	8,960 lm	152 lm/W
105W	GLIM-2-a-105-850-60	5000K	80	9,100 lm	155 lm/W
120W	GLIM-2-a-120-820-68	2000K	80	7,040 lm	104 lm/W
120W	GLIM-2-a-120-827-68	2700K	80	8,960 lm	133 lm/W
120W	GLIM-2-a-120-830-68	3000K	80	9,600 lm	143 lm/W
120W	GLIM-2-a-120-840-68	4000K	80	10,240 lm	152 lm/W
120W	GLIM-2-a-120-850-68	5000K	80	10,400 lm	155 lm/W
135W	GLIM-2-a-135-820-76	2000K	80	7,920 lm	104 lm/W
135W	GLIM-2-a-135-827-76	2700K	80	10,080 lm	133 lm/W
135W	GLIM-2-a-135-830-76	3000K	80	10,800 lm	143 lm/W
135W	GLIM-2-a-135-840-76	4000K	80	11,520 lm	152 lm/W
135W	GLIM-2-a-135-850-76	5000K	80	11,700 lm	155 lm/W
150W	GLIM-2-a-150-820-84	2000K	80	8,800 lm	104 lm/W
150W	GLIM-2-a-150-827-84	2700K	80	11,200 lm	133 lm/W
150W	GLIM-2-a-150-830-84	3000K	80	12,000 lm	143 lm/W
150W	GLIM-2-a-150-840-84	4000K	80	12,800 lm	152 lm/W
150W	GLIM-2-a-150-850-84	5000K	80	13,000 lm	155 lm/W
26W	GLIM-2-b-30-820-26	2000	80	2,640 lm	104 lm/W
26W	GLIM-2-b-30-827-26	2700	80	3,360 lm	133 lm/W
26W	GLIM-2-b-30-830-26	3000	80	3,600 lm	143 lm/W
26W	GLIM-2-b-30-840-26	4000	80	3,840 lm	152 lm/W
26W	GLIM-2-b-30-850-26	5000	80	3,900 lm	155 lm/W
34W	GLIM-2-b-36-820-34	2000	80	3,520 lm	104 lm/W
34W	GLIM-2-b-36-827-34	2700	80	4,480 lm	133 lm/W
34W	GLIM-2-b-36-830-34	3000	80	4,800 lm	143 lm/W
34W	GLIM-2-b-36-840-34	4000	80	5,120 lm	152 lm/W
34W	GLIM-2-b-36-850-34	5000	80	5,200 lm	155 lm/W
42W	GLIM-2-b-50-820-42	2000	80	4,400 lm	104 lm/W
42W	GLIM-2-b-50-827-42	2700	80	5,600 lm	133 lm/W
42W	GLIM-2-b-50-830-42	3000	80	6,000 lm	143 lm/W
42W	GLIM-2-b-50-840-42	4000	80	6,400 lm	152 lm/W
42W	GLIM-2-b-50-850-42	5000	80	6,500 lm	155 lm/W
51W	GLIM-2-b-60-820-51	2000	80	5,280 lm	104 lm/W
51W	GLIM-2-b-60-827-51	2700	80	6,720 lm	133 lm/W
51W	GLIM-2-b-60-830-51	3000	80	7,200 lm	143 lm/W
51W	GLIM-2-b-60-840-51	4000	80	7,680 lm	152 lm/W
51W	GLIM-2-b-60-850-51	5000	80	7,800 lm	155 lm/W
60W	GLIM-2-b-65-820-60	2000	80	6,160 lm	104 lm/W
60W	GLIM-2-b-65-827-60	2700	80	7,840 lm	133 lm/W
60W	GLIM-2-b-65-830-60	3000	80	8,400 lm	143 lm/W
60W	GLIM-2-b-65-840-60	4000	80	8,960 lm	152 lm/W
60W	GLIM-2-b-65-850-60	5000	80	9,100 lm	155 lm/W
68W	GLIM-2-b-75-820-68	2000	80	7,040 lm	104 lm/W
68W	GLIM-2-b-75-827-68	2700	80	8,960 lm	133 lm/W
68W	GLIM-2-b-75-830-68	3000	80	9,600 lm	143 lm/W
68W	GLIM-2-b-75-840-68	4000	80	10,240 lm	152 lm/W
68W	GLIM-2-b-75-850-68	5000	80	10,400 lm	155 lm/W
76W	GLIM-2-b-80-820-76	2000	80	7,920 lm	104 lm/W
76W	GLIM-2-b-80-827-76	2700	80	10,080 lm	133 lm/W
76W	GLIM-2-b-80-830-76	3000	80	10,800 lm	143 lm/W
76W	GLIM-2-b-80-840-76	4000	80	11,520 lm	152 lm/W
76W	GLIM-2-b-80-850-76	5000	80	11,700 lm	155 lm/W
84W	GLIM-2-b-90-820-84	2000	80	8,800 lm	104 lm/W
84W	GLIM-2-b-90-827-84	2700	80	11,200 lm	133 lm/W
84W	GLIM-2-b-90-830-84	3000	80	12,000 lm	143 lm/W
84W	GLIM-2-b-90-840-84	4000	80	12,800 lm	152 lm/W
84W	GLIM-2-b-90-850-84	5000	80	13,000 lm	155 lm/W
93W	GLIM-2-b-95-820-93	2000	80	9,680 lm	104 lm/W
93W	GLIM-2-b-95-827-93	2700	80	12,320 lm	133 lm/W
93W	GLIM-2-b-95-830-93	3000	80	13,200 lm	143 lm/W
93W	GLIM-2-b-95-840-93	4000	80	14,080 lm	152 lm/W
93W	GLIM-2-b-95-850-93	5000	80	14,300 lm	155 lm/W
100W	GLIM-2-b-105-820-100	2000	80	10,560 lm	104 lm/W
100W	GLIM-2-b-105-827-100	2700	80	13,440 lm	133 lm/W
100W	GLIM-2-b-105-830-100	3000	80	14,400 lm	143 lm/W
100W	GLIM-2-b-105-840-100	4000	80	15,360 lm	152 lm/W
100W	GLIM-2-b-105-850-100	5000	80	15,600 lm	155 lm/W
110W	GLIM-2-b-110-820-110	2000	80	11,440 lm	104 lm/W
110W	GLIM-2-b-110-827-110	2700	80	14,560 lm	133 lm/W
110W	GLIM-2-b-110-830-110	3000	80	15,600 lm	143 lm/W
110W	GLIM-2-b-110-840-110	4000	80	16,640 lm	152 lm/W
110W	GLIM-2-b-110-850-110	5000	80	16,900 lm	155 lm/W
118W	GLIM-2-b-120-820-118	2000	80	12,320 lm	104 lm/W
118W	GLIM-2-b-120-827-118	2700	80	15,680 lm	133 lm/W
118W	GLIM-2-b-120-830-118	3000	80	16,800 lm	143 lm/W
118W	GLIM-2-b-120-840-118	4000	80	17,920 lm	152 lm/W
118W	GLIM-2-b-120-850-118	5000	80	18,200 lm	155 lm/W
126W	GLIM-2-b-125-820-126	2000	80	13,200 lm	104 lm/W
126W	GLIM-2-b-125-827-126	2700	80	16,800 lm	133 lm/W
126W	GLIM-2-b-125-830-126	3000	80	18,000 lm	143 lm/W
126W	GLIM-2-b-125-840-126	4000	80	19,200 lm	152 lm/W
126W	GLIM-2-b-125-850-126	5000	80	19,500 lm	155 lm/W
135W	GLIM-2-b-132-820-135	2000	80	14,080 lm	104 lm/W
135W	GLIM-2-b-132-827-135	2700	80	17,920 lm	133 lm/W
135W	GLIM-2-b-132-830-135	3000	80	19,200 lm	143 lm/W
135W	GLIM-2-b-132-840-135	4000	80	20,480 lm	152 lm/W
135W	GLIM-2-b-132-850-135	5000	80	20,800 lm	155 lm/W
143W	GLIM-2-b-140-820-143	2000	80	14,960 lm	104 lm/W
143W	GLIM-2-b-140-827-143	2700	80	19,040 lm	133 lm/W
143W	GLIM-2-b-140-830-143	3000	80	20,400 lm	143 lm/W
143W	GLIM-2-b-140-840-143	4000	80	21,760 lm	152 lm/W
143W	GLIM-2-b-140-850-143	5000	80	22,100 lm	155 lm/W
152W	GLIM-2-b-150-820-152	2000	80	15,840 lm	104 lm/W
152W	GLIM-2-b-150-827-152	2700	80	20,160 lm	133 lm/W
152W	GLIM-2-b-150-830-152	3000	80	21,600 lm	143 lm/W
152W	GLIM-2-b-150-840-152	4000	80	23,040 lm	152 lm/W
152W	GLIM-2-b-150-850-152	5000	80	23,400 lm	155 lm/W
