SPC-XT series LED floodlight

Efficacy

145-182 lm/W

CRI

65-80

IP20

Warranty

5 years

The Techlumen LED floodlight SPC-XT is lightweight, with a small profile and extremely strong performance.
It is equipped with a bracket that can be easily mounted in difficult mounting positions. It is made of aluminum and painted with electrostatic powder paint in a wide RAL color selection.
It is produced in versions of 160W – 250W.
It is incredibly efficient, with efficiency of up to 182 lm / W and 43600 lm
The CCT can be selected between 2000K (warm white), as and 6500K (cool white). The projector is IP66-rated. The optics are made from borosilicate glass of high thermal and mechanical resistance.
There is a selection of beam angles from 30^o to 120^o.
It has a 5-year warranty and a durability index of L80> 70000h, while the LED chip has a 10-year factory warranty.

Luminaire brochure

Installation Manual

✉️ Request Quote Download PDF

📐

Calculate Required Luminaires

Via Techlumen Lux Calculator

📄

Luminaire Brochure

Detailed specifications

🔧

Installation Manual

Mounting and wiring instructions

📊

Photometric Files

LDT / IES for lighting design

Technical Specifications

Luminous Flux 24300 - 43600 lm

Power 160 - 250W

Ambient Temperature -30°C to +40°C

Efficacy 145 - 182 lm/W

CRI 65-80

CCT 3000K-6500K

IP Rating IP20

IK Rating IK06

Body Aluminium

Dimensions 34mm x 62mm x (400- 700)

Weight 1 - 1.5 kg

Warranty 5 years

Certifications & Compliance

CE ROHS EN 60598-1 EN 60598-2 EN 61000-3 EN 61547 EN 55015 EN 62471 EN 62493 EN 63000

Available Versions

Power	Code	CCT	CRI	Lumen	Efficacy
160W	SPC-XT-620-160	2000K	65	24,300 lm	152 lm/W
160W	SPC-XT-827-160	2700K	80	26,200 lm	164 lm/W
160W	SPC-XT-830-160	3000K	80	26,800 lm	168 lm/W
160W	SPC-XT-835-160	3500K	80	27,000 lm	169 lm/W
160W	SPC-XT-840-160	4000K	80	27,120 lm	170 lm/W
160W	SPC-XT-750-160	5000K	70	27,160 lm	170 lm/W
160W	SPC-XT-850-160	5000K	80	26,600 lm	166 lm/W
160W	SPC-XT-757-160	5700K	70	26,400 lm	165 lm/W
160W	SPC-XT-765-160	6500K	70	26,400 lm	165 lm/W
172W	SPC-XT-620-172	2000K	65	25,900 lm	151 lm/W
172W	SPC-XT-827-172	2700K	80	28,000 lm	163 lm/W
172W	SPC-XT-830-172	3000K	80	28,600 lm	166 lm/W
172W	SPC-XT-835-172	3500K	80	28,700 lm	167 lm/W
172W	SPC-XT-840-172	4000K	80	28,900 lm	168 lm/W
172W	SPC-XT-750-172	5000K	70	29,000 lm	169 lm/W
172W	SPC-XT-850-172	5000K	80	28,340 lm	165 lm/W
172W	SPC-XT-757-172	5700K	70	28,220 lm	164 lm/W
172W	SPC-XT-765-172	6500K	70	28,220 lm	164 lm/W
200W	SPC-XT-620-200	2000K	65	30,040 lm	150 lm/W
200W	SPC-XT-827-200	2700K	80	31,560 lm	158 lm/W
200W	SPC-XT-830-200	3000K	80	33,520 lm	168 lm/W
200W	SPC-XT-835-200	3500K	80	34,320 lm	172 lm/W
200W	SPC-XT-840-200	4000K	80	34,520 lm	173 lm/W
200W	SPC-XT-750-200	5000K	70	36,300 lm	182 lm/W
200W	SPC-XT-850-200	5000K	80	34,920 lm	175 lm/W
200W	SPC-XT-757-200	5700K	70	35,300 lm	177 lm/W
200W	SPC-XT-765-200	6500K	70	35,300 lm	177 lm/W
220W	SPC-XT-620-220	2000K	65	32,400 lm	147 lm/W
220W	SPC-XT-827-220	2700K	80	33,700 lm	148 lm/W
220W	SPC-XT-830-220	3000K	80	35,800 lm	163 lm/W
220W	SPC-XT-835-220	3500K	80	36,600 lm	166 lm/W
220W	SPC-XT-840-220	4000K	80	36,800 lm	167 lm/W
220W	SPC-XT-750-220	5000K	70	38,700 lm	176 lm/W
220W	SPC-XT-850-220	5000K	80	37,200 lm	169 lm/W
220W	SPC-XT-757-220	5700K	70	37,700 lm	171 lm/W
220W	SPC-XT-765-220	6500K	70	37,700 lm	171 lm/W
250W	SPC-XT-620-250	2000K	65	36,400 lm	145 lm/W
250W	SPC-XT-827-250	2700K	80	37,940 lm	152 lm/W
250W	SPC-XT-830-250	3000K	80	40,320 lm	161 lm/W
250W	SPC-XT-835-250	3500K	80	41,200 lm	165 lm/W
250W	SPC-XT-840-250	4000K	80	41,400 lm	166 lm/W
250W	SPC-XT-750-250	5000K	70	43,600 lm	174 lm/W
250W	SPC-XT-850-250	5000K	80	41,980 lm	168 lm/W
250W	SPC-XT-757-250	5700K	70	42,400 lm	170 lm/W
250W	SPC-XT-765-250	6500K	70	42,400 lm	170 lm/W
