GLIM-R Recessed Linear LED

Efficacy

133-180 lm/W

CRI

IP66

Warranty

5 years

The Techlumen© GLIM-R linear recessed luminaires are ideal for architectural interior lighting.

They are IP66 rated with excellent durability. Constructed from aluminium and optionally powder-coated in any RAL colour.

Lightweight and slim-profiled, they are produced in various lengths and output options, featuring five beam configurations: 11°, 17°, 22°, wallwashing and oval — all with UGR<19 for superior visual comfort.

GLIM-R luminaires come with a 5-year factory warranty.

Applications:
Lobbies · Offices · Galleries · Residences · Museums · Hotels

✉️ Request Quote Download PDF

📐

Calculate Required Luminaires

Via Techlumen Lux Calculator

📄

Luminaire Brochure

Detailed specifications

📊

Photometric Files

LDT / IES for lighting design

Technical Specifications

Luminous Flux 1272 - 12240 lm

Power 8 - 76W

Ambient Temperature -30°C to +50°C

Efficacy 133 - 180 lm/W

Power Factor 0.95

CRI 80

CCT 2700KK-5000KK

IP Rating IP66

IK Rating IK09

Body Aluminium

Finishing Powder Coating / Anodized aluminium

Dimensions 71mm x 75mm x (350 - 1000)mm

Weight 0.6 - 2.7 kg

Warranty 5 years

Certifications & Compliance

EN 60598-1:2021 EN 60598-2-1: 2021 EN 60598-2-2: 2023 EN 61000-3-2:2019 EN 61000-3-3:2013 + AMD1:2017 + AMD2:2021 EN 61547:2020 EN 55015:2019 EN 62471:2008 EN 62493:2015 EN 50581:2012 Directive (LVD) -2014/35/EU Directive (EMC) -2014/30/EU Directive (RoHS) -2011/65/EC Directive (REACH) -2006/1907/EC Directive (EuP) -2009/125/EC Directive (GPS) -2001/95/EU

Available Versions

Power	Code	CCT	CRI	Lumen	Efficacy
8W	GLIM-R-30-827-8	2700	80	1,272 lm	159 lm/W
8W	GLIM-R-30-830-8	3000	80	1,272 lm	159 lm/W
8W	GLIM-R-30-840-8	4000	80	1,357 lm	170 lm/W
8W	GLIM-R-30-850-8	5000	80	1,442 lm	180 lm/W
17W	GLIM-R-30-827-17	2700	80	2,400 lm	133 lm/W
17W	GLIM-R-30-830-17	3000	80	2,400 lm	133 lm/W
17W	GLIM-R-30-840-17	4000	80	2,560 lm	142 lm/W
17W	GLIM-R-30-850-17	5000	80	2,720 lm	151 lm/W
13W	GLIM-R-40-827-13	2700	80	1,908 lm	159 lm/W
13W	GLIM-R-40-830-13	3000	80	1,908 lm	159 lm/W
13W	GLIM-R-40-840-13	4000	80	2,035 lm	170 lm/W
13W	GLIM-R-40-850-13	5000	80	2,162 lm	180 lm/W
25W	GLIM-R-40-827-25	2700	80	3,600 lm	133 lm/W
25W	GLIM-R-40-830-25	3000	80	3,600 lm	133 lm/W
25W	GLIM-R-40-840-25	4000	80	3,840 lm	142 lm/W
25W	GLIM-R-40-850-25	5000	80	4,080 lm	151 lm/W
17W	GLIM-R-50-827-17	2700	80	2,544 lm	159 lm/W
17W	GLIM-R-50-830-17	3000	80	2,544 lm	159 lm/W
17W	GLIM-R-50-840-17	4000	80	2,713 lm	170 lm/W
17W	GLIM-R-50-850-17	5000	80	2,883 lm	180 lm/W
34W	GLIM-R-50-827-34	2700	80	4,800 lm	133 lm/W
34W	GLIM-R-50-830-34	3000	80	4,800 lm	133 lm/W
34W	GLIM-R-50-840-34	4000	80	5,120 lm	142 lm/W
34W	GLIM-R-50-850-34	5000	80	5,440 lm	151 lm/W
21W	GLIM-R-60-827-21	2700	80	3,180 lm	159 lm/W
21W	GLIM-R-60-830-21	3000	80	3,180 lm	159 lm/W
21W	GLIM-R-60-840-21	4000	80	3,392 lm	170 lm/W
21W	GLIM-R-60-850-21	5000	80	3,604 lm	180 lm/W
42W	GLIM-R-60-827-42	2700	80	6,000 lm	133 lm/W
42W	GLIM-R-60-830-42	3000	80	6,000 lm	133 lm/W
42W	GLIM-R-60-840-42	4000	80	6,400 lm	142 lm/W
42W	GLIM-R-60-850-42	5000	80	6,800 lm	151 lm/W
25W	GLIM-R-70-827-25	2700	80	3,816 lm	159 lm/W
25W	GLIM-R-70-830-25	3000	80	3,816 lm	159 lm/W
25W	GLIM-R-70-840-25	4000	80	4,070 lm	170 lm/W
25W	GLIM-R-70-850-25	5000	80	4,325 lm	180 lm/W
50W	GLIM-R-70-827-50	2700	80	7,200 lm	133 lm/W
50W	GLIM-R-70-830-50	3000	80	7,200 lm	133 lm/W
50W	GLIM-R-70-840-50	4000	80	7,680 lm	142 lm/W
50W	GLIM-R-70-850-50	5000	80	8,160 lm	151 lm/W
29W	GLIM-R-80-827-29	2700	80	4,452 lm	159 lm/W
29W	GLIM-R-80-830-29	3000	80	4,452 lm	159 lm/W
29W	GLIM-R-80-840-29	4000	80	4,749 lm	170 lm/W
29W	GLIM-R-80-850-29	5000	80	5,046 lm	180 lm/W
59W	GLIM-R-80-827-59	2700	80	8,400 lm	133 lm/W
59W	GLIM-R-80-830-59	3000	80	8,400 lm	133 lm/W
59W	GLIM-R-80-840-59	4000	80	8,960 lm	142 lm/W
59W	GLIM-R-80-850-59	5000	80	9,520 lm	151 lm/W
34W	GLIM-R-90-827-34	2700	80	5,088 lm	159 lm/W
34W	GLIM-R-90-830-34	3000	80	5,088 lm	159 lm/W
34W	GLIM-R-90-840-34	4000	80	5,427 lm	170 lm/W
34W	GLIM-R-90-850-34	5000	80	5,766 lm	180 lm/W
67W	GLIM-R-90-827-67	2700	80	9,600 lm	133 lm/W
67W	GLIM-R-90-830-67	3000	80	9,600 lm	133 lm/W
67W	GLIM-R-90-840-67	4000	80	10,240 lm	142 lm/W
67W	GLIM-R-90-850-67	5000	80	10,880 lm	151 lm/W
38W	GLIM-R-100-827-38	2700	80	5,724 lm	159 lm/W
38W	GLIM-R-100-830-38	3000	80	5,724 lm	159 lm/W
38W	GLIM-R-100-840-38	4000	80	6,106 lm	170 lm/W
38W	GLIM-R-100-850-38	5000	80	6,487 lm	180 lm/W
76W	GLIM-R-100-827-76	2700	80	10,800 lm	133 lm/W
76W	GLIM-R-100-830-76	3000	80	10,800 lm	133 lm/W
76W	GLIM-R-100-840-76	4000	80	11,520 lm	142 lm/W
76W	GLIM-R-100-850-76	5000	80	12,240 lm	151 lm/W
