ECLIPSE-Α low UGR linear LED

Efficacy

126-177 lm/W

CRI

80-90

IP20

Warranty

5 years

ECLIPSE-A linear LED luminaires provide highly comfortable lighting with UGR<19, distributing light evenly throughout the space without visible glare from most viewing angles.

They are the ideal solution for offices, meeting rooms and workspaces where visual comfort and lighting quality are essential. They can be recessed, surface-mounted or suspended.

Optional features include dimming (wired or wireless) and emergency lighting up to 3 hours. They offer a lifetime rating of L80B10 > 80,000 h and come with a 5-year factory warranty.

Applications:
Offices · Meeting rooms · Educational facilities · Retail · Residential interiors

✉️ Request Quote Download PDF

📐

Calculate Required Luminaires

Via Techlumen Lux Calculator

📄

Luminaire Brochure

Detailed specifications

🔧

Installation Manual

Mounting and wiring instructions

📊

Photometric Files

LDT / IES for lighting design

Technical Specifications

Luminous Flux 821 - 21276 lm

Power 6 - 135W

Efficacy 126 - 177 lm/W

CRI 80-90

CCT 3000K-4000K

IP Rating IP20

IK Rating IK06

Dimensions Aluminium

Warranty 5 years

Certifications & Compliance

ROHS EN 60598-1 EN 60598-2 EN 61000-3 EN 61547 EN 55015 EN 62471 EN 62493 EN 50581

Available Versions

Power	Code	CCT	CRI	Lumen	Efficacy
6W	ECLIPSE-A-19-830-6	3000K	80	946 lm	80 lm/W
6W	ECLIPSE-A-19-840-6	4000K	80	990 lm	80 lm/W
6W	ECLIPSE-A-19-930-6	3000K	90	821 lm	90 lm/W
6W	ECLIPSE-A-19-940-6	4000K	90	857 lm	90 lm/W
7.5W	ECLIPSE-A-19-830-8	3000K	80	1,130 lm	80 lm/W
7.5W	ECLIPSE-A-19-840-8	4000K	80	1,182 lm	80 lm/W
7.5W	ECLIPSE-A-19-930-8	3000K	90	980 lm	90 lm/W
7.5W	ECLIPSE-A-19-940-8	4000K	90	1,023 lm	90 lm/W
12W	ECLIPSE-A-32-830-12	3000K	80	1,892 lm	80 lm/W
12W	ECLIPSE-A-32-840-12	4000K	80	1,980 lm	80 lm/W
12W	ECLIPSE-A-32-930-12	3000K	90	1,642 lm	90 lm/W
12W	ECLIPSE-A-32-940-12	4000K	90	1,714 lm	90 lm/W
15W	ECLIPSE-A-32-830-15	3000K	80	2,260 lm	80 lm/W
15W	ECLIPSE-A-32-840-15	4000K	80	2,364 lm	80 lm/W
15W	ECLIPSE-A-32-930-15	3000K	90	1,960 lm	90 lm/W
15W	ECLIPSE-A-32-940-15	4000K	90	2,046 lm	90 lm/W
18.5W	ECLIPSE-A-48-830-18	3000K	80	2,838 lm	80 lm/W
18.5W	ECLIPSE-A-48-840-18	4000K	80	2,970 lm	80 lm/W
18.5W	ECLIPSE-A-48-930-18	3000K	90	2,463 lm	90 lm/W
18.5W	ECLIPSE-A-48-940-18	4000K	90	2,571 lm	90 lm/W
22.5W	ECLIPSE-A-48-830-23	3000K	80	3,390 lm	80 lm/W
22.5W	ECLIPSE-A-48-840-23	4000K	80	3,546 lm	80 lm/W
22.5W	ECLIPSE-A-48-930-23	3000K	90	2,940 lm	90 lm/W
22.5W	ECLIPSE-A-48-940-23	4000K	90	3,069 lm	90 lm/W
25W	ECLIPSE-A-64-830-25	3000K	80	3,784 lm	80 lm/W
25W	ECLIPSE-A-64-840-25	4000K	80	3,960 lm	80 lm/W
25W	ECLIPSE-A-64-930-25	3000K	90	3,284 lm	90 lm/W
25W	ECLIPSE-A-64-940-25	4000K	90	3,428 lm	90 lm/W
30W	ECLIPSE-A-64-830-30	3000K	80	4,520 lm	80 lm/W
30W	ECLIPSE-A-64-840-30	4000K	80	4,728 lm	80 lm/W
30W	ECLIPSE-A-64-930-30	3000K	90	3,920 lm	90 lm/W
30W	ECLIPSE-A-64-940-30	4000K	90	4,092 lm	90 lm/W
31W	ECLIPSE-A-80-830-31	3000K	80	4,730 lm	80 lm/W
31W	ECLIPSE-A-80-840-31	4000K	80	4,950 lm	80 lm/W
31W	ECLIPSE-A-80-930-31	3000K	90	4,105 lm	90 lm/W
31W	ECLIPSE-A-80-940-31	4000K	90	4,285 lm	90 lm/W
37W	ECLIPSE-A-80-830-37	3000K	80	5,650 lm	80 lm/W
37W	ECLIPSE-A-80-840-37	4000K	80	5,910 lm	80 lm/W
37W	ECLIPSE-A-80-930-37	3000K	90	4,900 lm	90 lm/W
37W	ECLIPSE-A-80-940-37	4000K	90	5,115 lm	90 lm/W
37W	ECLIPSE-A-96-830-37	3000K	80	5,676 lm	80 lm/W
37W	ECLIPSE-A-96-840-37	4000K	80	5,940 lm	80 lm/W
37W	ECLIPSE-A-96-930-37	3000K	90	4,926 lm	90 lm/W
37W	ECLIPSE-A-96-940-37	4000K	90	5,142 lm	90 lm/W
45W	ECLIPSE-A-96-830-45	3000K	80	6,780 lm	80 lm/W
45W	ECLIPSE-A-96-840-45	4000K	80	7,092 lm	80 lm/W
45W	ECLIPSE-A-96-930-45	3000K	90	5,880 lm	90 lm/W
45W	ECLIPSE-A-96-940-45	4000K	90	6,138 lm	90 lm/W
43W	ECLIPSE-A-112-830-43	3000K	80	6,622 lm	80 lm/W
43W	ECLIPSE-A-112-840-43	4000K	80	6,930 lm	80 lm/W
43W	ECLIPSE-A-112-930-43	3000K	90	5,747 lm	90 lm/W
43W	ECLIPSE-A-112-940-43	4000K	90	5,999 lm	90 lm/W
52W	ECLIPSE-A-112-830-52	3000K	80	7,910 lm	80 lm/W
52W	ECLIPSE-A-112-840-52	4000K	80	8,274 lm	80 lm/W
52W	ECLIPSE-A-112-930-52	3000K	90	6,860 lm	90 lm/W
52W	ECLIPSE-A-112-940-52	4000K	90	7,161 lm	90 lm/W
49W	ECLIPSE-A-128-830-49	3000K	80	7,568 lm	80 lm/W
49W	ECLIPSE-A-128-840-49	4000K	80	7,920 lm	80 lm/W
49W	ECLIPSE-A-128-930-49	3000K	90	6,568 lm	90 lm/W
49W	ECLIPSE-A-128-940-49	4000K	90	6,856 lm	90 lm/W
60W	ECLIPSE-A-128-830-60	3000K	80	9,040 lm	80 lm/W
60W	ECLIPSE-A-128-840-60	4000K	80	9,456 lm	80 lm/W
60W	ECLIPSE-A-128-930-60	3000K	90	7,840 lm	90 lm/W
60W	ECLIPSE-A-128-940-60	4000K	90	8,184 lm	90 lm/W
55W	ECLIPSE-A-144-830-55	3000K	80	8,514 lm	80 lm/W
55W	ECLIPSE-A-144-840-55	4000K	80	8,910 lm	80 lm/W
55W	ECLIPSE-A-144-930-55	3000K	90	7,389 lm	90 lm/W
55W	ECLIPSE-A-144-940-55	4000K	90	7,713 lm	90 lm/W
67W	ECLIPSE-A-144-830-67	3000K	80	10,170 lm	80 lm/W
67W	ECLIPSE-A-144-840-67	4000K	80	10,638 lm	80 lm/W
67W	ECLIPSE-A-144-930-67	3000K	90	8,820 lm	90 lm/W
67W	ECLIPSE-A-144-940-67	4000K	90	9,207 lm	90 lm/W
62W	ECLIPSE-A-160-830-62	3000K	80	9,460 lm	80 lm/W
62W	ECLIPSE-A-160-840-62	4000K	80	9,900 lm	80 lm/W
62W	ECLIPSE-A-160-930-62	3000K	90	8,210 lm	90 lm/W
62W	ECLIPSE-A-160-940-62	4000K	90	8,570 lm	90 lm/W
75W	ECLIPSE-A-160-830-75	3000K	80	11,300 lm	80 lm/W
75W	ECLIPSE-A-160-840-75	4000K	80	11,820 lm	80 lm/W
75W	ECLIPSE-A-160-930-75	3000K	90	9,800 lm	90 lm/W
75W	ECLIPSE-A-160-940-75	4000K	90	10,230 lm	90 lm/W
68W	ECLIPSE-A-176-830-68	3000K	80	10,406 lm	80 lm/W
68W	ECLIPSE-A-176-840-68	4000K	80	10,890 lm	80 lm/W
68W	ECLIPSE-A-176-930-68	3000K	90	9,031 lm	90 lm/W
68W	ECLIPSE-A-176-940-68	4000K	90	9,427 lm	90 lm/W
82W	ECLIPSE-A-176-830-82	3000K	80	12,430 lm	80 lm/W
82W	ECLIPSE-A-176-840-82	4000K	80	13,002 lm	80 lm/W
82W	ECLIPSE-A-176-930-82	3000K	90	10,780 lm	90 lm/W
82W	ECLIPSE-A-176-940-82	4000K	90	11,253 lm	90 lm/W
74W	ECLIPSE-A-192-830-74	3000K	80	11,352 lm	80 lm/W
74W	ECLIPSE-A-192-840-74	4000K	80	11,880 lm	80 lm/W
74W	ECLIPSE-A-192-930-74	3000K	90	9,852 lm	90 lm/W
74W	ECLIPSE-A-192-940-74	4000K	90	10,284 lm	90 lm/W
90W	ECLIPSE-A-192-830-90	3000K	80	13,560 lm	80 lm/W
90W	ECLIPSE-A-192-840-90	4000K	80	14,184 lm	80 lm/W
90W	ECLIPSE-A-192-930-90	3000K	90	11,760 lm	90 lm/W
90W	ECLIPSE-A-192-940-90	4000K	90	12,276 lm	90 lm/W
80W	ECLIPSE-A-208-830-80	3000K	80	12,298 lm	80 lm/W
80W	ECLIPSE-A-208-840-80	4000K	80	12,870 lm	80 lm/W
80W	ECLIPSE-A-208-930-80	3000K	90	10,673 lm	90 lm/W
80W	ECLIPSE-A-208-940-80	4000K	90	11,141 lm	90 lm/W
97W	ECLIPSE-A-208-830-97	3000K	80	14,690 lm	80 lm/W
97W	ECLIPSE-A-208-840-97	4000K	80	15,366 lm	80 lm/W
97W	ECLIPSE-A-208-930-97	3000K	90	12,740 lm	90 lm/W
97W	ECLIPSE-A-208-940-97	4000K	90	13,299 lm	90 lm/W
86W	ECLIPSE-A-223-830-86	3000K	80	13,244 lm	80 lm/W
86W	ECLIPSE-A-223-840-86	4000K	80	13,860 lm	80 lm/W
86W	ECLIPSE-A-223-930-86	3000K	90	11,494 lm	90 lm/W
86W	ECLIPSE-A-223-940-86	4000K	90	11,998 lm	90 lm/W
105W	ECLIPSE-A-223-830-105	3000K	80	15,820 lm	80 lm/W
105W	ECLIPSE-A-223-840-105	4000K	80	16,548 lm	80 lm/W
105W	ECLIPSE-A-223-930-105	3000K	90	13,720 lm	90 lm/W
105W	ECLIPSE-A-223-940-105	4000K	90	14,322 lm	90 lm/W
93W	ECLIPSE-A-240-830-93	3000K	80	14,190 lm	80 lm/W
93W	ECLIPSE-A-240-840-93	4000K	80	14,850 lm	80 lm/W
93W	ECLIPSE-A-240-930-93	3000K	90	12,315 lm	90 lm/W
93W	ECLIPSE-A-240-940-93	4000K	90	12,855 lm	90 lm/W
113W	ECLIPSE-A-240-830-113	3000K	80	16,950 lm	80 lm/W
113W	ECLIPSE-A-240-840-113	4000K	80	17,730 lm	80 lm/W
113W	ECLIPSE-A-240-930-113	3000K	90	14,700 lm	90 lm/W
113W	ECLIPSE-A-240-940-113	4000K	90	15,345 lm	90 lm/W
98W	ECLIPSE-A-255-830-98	3000K	80	15,136 lm	80 lm/W
98W	ECLIPSE-A-255-840-98	4000K	80	15,840 lm	80 lm/W
98W	ECLIPSE-A-255-930-98	3000K	90	13,136 lm	90 lm/W
98W	ECLIPSE-A-255-940-98	4000K	90	13,712 lm	90 lm/W
120W	ECLIPSE-A-255-830-120	3000K	80	18,080 lm	80 lm/W
120W	ECLIPSE-A-255-840-120	4000K	80	18,912 lm	80 lm/W
120W	ECLIPSE-A-255-930-120	3000K	90	15,680 lm	90 lm/W
120W	ECLIPSE-A-255-940-120	4000K	90	16,368 lm	90 lm/W
105W	ECLIPSE-A-271-830-105	3000K	80	16,082 lm	80 lm/W
105W	ECLIPSE-A-271-840-105	4000K	80	16,830 lm	80 lm/W
105W	ECLIPSE-A-271-930-105	3000K	90	13,957 lm	90 lm/W
105W	ECLIPSE-A-271-940-105	4000K	90	14,569 lm	90 lm/W
127W	ECLIPSE-A-271-830-127	3000K	80	19,210 lm	80 lm/W
127W	ECLIPSE-A-271-840-127	4000K	80	20,094 lm	80 lm/W
127W	ECLIPSE-A-271-930-127	3000K	90	16,660 lm	90 lm/W
127W	ECLIPSE-A-271-940-127	4000K	90	17,391 lm	90 lm/W
111W	ECLIPSE-A-287-830-111	3000K	80	17,028 lm	80 lm/W
111W	ECLIPSE-A-287-840-111	4000K	80	17,820 lm	80 lm/W
111W	ECLIPSE-A-287-930-111	3000K	90	14,778 lm	90 lm/W
111W	ECLIPSE-A-287-940-111	4000K	90	15,426 lm	90 lm/W
135W	ECLIPSE-A-287-830-135	3000K	80	20,340 lm	80 lm/W
135W	ECLIPSE-A-287-840-135	4000K	80	21,276 lm	80 lm/W
135W	ECLIPSE-A-287-930-135	3000K	90	17,640 lm	90 lm/W
135W	ECLIPSE-A-287-940-135	4000K	90	18,414 lm	90 lm/W
