ECLIPSE-A – γραμμικό φωτιστικό LED υψηλής οπτικής άνεσης

Γραμμικά φωτιστικά LED

ECLIPSE-A – γραμμικό φωτιστικό LED υψηλής οπτικής άνεσης

Efficacy

126-177 lm/W

CRI

80-90

Τα γραμμικά φωτιστικά ECLIPSE-A προσφέρουν υψηλής ποιότητας φωτισμό με UGR<19, διαχέοντας το φως ομοιόμορφα χωρίς η πηγή να είναι ορατή από τους περισσότερους οπτικούς άξονες.

Είναι ιδανική λύση για γραφεία, αίθουσες συνεδριάσεων και χώρους εργασίας, όπου απαιτείται οπτική άνεση και ποιοτικός φωτισμός. Τοποθετούνται σε ψευδοροφή, οροφή ή αναρτώμενα.

Προαιρετικά διαθέτουν dimming (ενσύρματο ή ασύρματο) και λειτουργία ανάγκης έως 3 ώρες. Η διάρκεια ζωής τους φτάνει τα L80B10 > 80 000 h, ενώ καλύπτονται από 5ετή εργοστασιακή εγγύηση.

Εφαρμογές:
Γραφεία · Αίθουσες συνεδριάσεων · Εκπαιδευτικοί χώροι · Καταστήματα · Κατοικίες

✉️ Request Quote Download PDF

📐

Calculate Required Luminaires

Via Techlumen Lux Calculator

📄

Luminaire Brochure

Detailed specifications

🔧

Installation Manual

Mounting and wiring instructions

📊

Photometric Files

LDT / IES for lighting design

Technical Specifications

Power 6 - 135W

Efficacy 126 - 177 lm/W

Power Factor 0.95

CRI 80-90

CCT 3000K-4000K

Certifications & Compliance

ROHS EN 60598-1 EN 60598-2 EN 61000-3 EN 61547 EN 55015 EN 62471 EN 62493 EN 50581

Available Versions

Power	Code	CCT	CRI	Lumen	Efficacy
6W	ECLIPSE-A-19-830-6	3000K	80	946 lm	80 lm/W
6W	ECLIPSE-A-19-840-6	4000K	80	990 lm	80 lm/W
6W	ECLIPSE-A-19-930-6	3000K	90	821 lm	90 lm/W
6W	ECLIPSE-A-19-940-6	4000K	90	857 lm	90 lm/W
7.5W	ECLIPSE-A-19-830-8	3000K	80	1,130 lm	80 lm/W
7.5W	ECLIPSE-A-19-840-8	4000K	80	1,182 lm	80 lm/W
7.5W	ECLIPSE-A-19-930-8	3000K	90	980 lm	90 lm/W
7.5W	ECLIPSE-A-19-940-8	4000K	90	1,023 lm	90 lm/W
12W	ECLIPSE-A-32-830-12	3000K	80	1,892 lm	80 lm/W
12W	ECLIPSE-A-32-840-12	4000K	80	1,980 lm	80 lm/W
12W	ECLIPSE-A-32-930-12	3000K	90	1,642 lm	90 lm/W
12W	ECLIPSE-A-32-940-12	4000K	90	1,714 lm	90 lm/W
15W	ECLIPSE-A-32-830-15	3000K	80	2,260 lm	80 lm/W
15W	ECLIPSE-A-32-840-15	4000K	80	2,364 lm	80 lm/W
15W	ECLIPSE-A-32-930-15	3000K	90	1,960 lm	90 lm/W
15W	ECLIPSE-A-32-940-15	4000K	90	2,046 lm	90 lm/W
18.5W	ECLIPSE-A-48-830-18	3000K	80	2,838 lm	80 lm/W
18.5W	ECLIPSE-A-48-840-18	4000K	80	2,970 lm	80 lm/W
18.5W	ECLIPSE-A-48-930-18	3000K	90	2,463 lm	90 lm/W
18.5W	ECLIPSE-A-48-940-18	4000K	90	2,571 lm	90 lm/W
22.5W	ECLIPSE-A-48-830-23	3000K	80	3,390 lm	80 lm/W
22.5W	ECLIPSE-A-48-840-23	4000K	80	3,546 lm	80 lm/W
22.5W	ECLIPSE-A-48-930-23	3000K	90	2,940 lm	90 lm/W
22.5W	ECLIPSE-A-48-940-23	4000K	90	3,069 lm	90 lm/W
25W	ECLIPSE-A-64-830-25	3000K	80	3,784 lm	80 lm/W
25W	ECLIPSE-A-64-840-25	4000K	80	3,960 lm	80 lm/W
25W	ECLIPSE-A-64-930-25	3000K	90	3,284 lm	90 lm/W
25W	ECLIPSE-A-64-940-25	4000K	90	3,428 lm	90 lm/W
30W	ECLIPSE-A-64-830-30	3000K	80	4,520 lm	80 lm/W
30W	ECLIPSE-A-64-840-30	4000K	80	4,728 lm	80 lm/W
30W	ECLIPSE-A-64-930-30	3000K	90	3,920 lm	90 lm/W
30W	ECLIPSE-A-64-940-30	4000K	90	4,092 lm	90 lm/W
31W	ECLIPSE-A-80-830-31	3000K	80	4,730 lm	80 lm/W
31W	ECLIPSE-A-80-840-31	4000K	80	4,950 lm	80 lm/W
31W	ECLIPSE-A-80-930-31	3000K	90	4,105 lm	90 lm/W
31W	ECLIPSE-A-80-940-31	4000K	90	4,285 lm	90 lm/W
37W	ECLIPSE-A-80-830-37	3000K	80	5,650 lm	80 lm/W
37W	ECLIPSE-A-80-840-37	4000K	80	5,910 lm	80 lm/W
37W	ECLIPSE-A-80-930-37	3000K	90	4,900 lm	90 lm/W
37W	ECLIPSE-A-80-940-37	4000K	90	5,115 lm	90 lm/W
37W	ECLIPSE-A-96-830-37	3000K	80	5,676 lm	80 lm/W
37W	ECLIPSE-A-96-840-37	4000K	80	5,940 lm	80 lm/W
37W	ECLIPSE-A-96-930-37	3000K	90	4,926 lm	90 lm/W
37W	ECLIPSE-A-96-940-37	4000K	90	5,142 lm	90 lm/W
45W	ECLIPSE-A-96-830-45	3000K	80	6,780 lm	80 lm/W
45W	ECLIPSE-A-96-840-45	4000K	80	7,092 lm	80 lm/W
45W	ECLIPSE-A-96-930-45	3000K	90	5,880 lm	90 lm/W
45W	ECLIPSE-A-96-940-45	4000K	90	6,138 lm	90 lm/W
43W	ECLIPSE-A-112-830-43	3000K	80	6,622 lm	80 lm/W
43W	ECLIPSE-A-112-840-43	4000K	80	6,930 lm	80 lm/W
43W	ECLIPSE-A-112-930-43	3000K	90	5,747 lm	90 lm/W
43W	ECLIPSE-A-112-940-43	4000K	90	5,999 lm	90 lm/W
52W	ECLIPSE-A-112-830-52	3000K	80	7,910 lm	80 lm/W
52W	ECLIPSE-A-112-840-52	4000K	80	8,274 lm	80 lm/W
52W	ECLIPSE-A-112-930-52	3000K	90	6,860 lm	90 lm/W
52W	ECLIPSE-A-112-940-52	4000K	90	7,161 lm	90 lm/W
49W	ECLIPSE-A-128-830-49	3000K	80	7,568 lm	80 lm/W
49W	ECLIPSE-A-128-840-49	4000K	80	7,920 lm	80 lm/W
49W	ECLIPSE-A-128-930-49	3000K	90	6,568 lm	90 lm/W
49W	ECLIPSE-A-128-940-49	4000K	90	6,856 lm	90 lm/W
60W	ECLIPSE-A-128-830-60	3000K	80	9,040 lm	80 lm/W
60W	ECLIPSE-A-128-840-60	4000K	80	9,456 lm	80 lm/W
60W	ECLIPSE-A-128-930-60	3000K	90	7,840 lm	90 lm/W
60W	ECLIPSE-A-128-940-60	4000K	90	8,184 lm	90 lm/W
55W	ECLIPSE-A-144-830-55	3000K	80	8,514 lm	80 lm/W
55W	ECLIPSE-A-144-840-55	4000K	80	8,910 lm	80 lm/W
55W	ECLIPSE-A-144-930-55	3000K	90	7,389 lm	90 lm/W
55W	ECLIPSE-A-144-940-55	4000K	90	7,713 lm	90 lm/W
67W	ECLIPSE-A-144-830-67	3000K	80	10,170 lm	80 lm/W
67W	ECLIPSE-A-144-840-67	4000K	80	10,638 lm	80 lm/W
67W	ECLIPSE-A-144-930-67	3000K	90	8,820 lm	90 lm/W
67W	ECLIPSE-A-144-940-67	4000K	90	9,207 lm	90 lm/W
62W	ECLIPSE-A-160-830-62	3000K	80	9,460 lm	80 lm/W
62W	ECLIPSE-A-160-840-62	4000K	80	9,900 lm	80 lm/W
62W	ECLIPSE-A-160-930-62	3000K	90	8,210 lm	90 lm/W
62W	ECLIPSE-A-160-940-62	4000K	90	8,570 lm	90 lm/W
75W	ECLIPSE-A-160-830-75	3000K	80	11,300 lm	80 lm/W
75W	ECLIPSE-A-160-840-75	4000K	80	11,820 lm	80 lm/W
75W	ECLIPSE-A-160-930-75	3000K	90	9,800 lm	90 lm/W
75W	ECLIPSE-A-160-940-75	4000K	90	10,230 lm	90 lm/W
68W	ECLIPSE-A-176-830-68	3000K	80	10,406 lm	80 lm/W
68W	ECLIPSE-A-176-840-68	4000K	80	10,890 lm	80 lm/W
68W	ECLIPSE-A-176-930-68	3000K	90	9,031 lm	90 lm/W
68W	ECLIPSE-A-176-940-68	4000K	90	9,427 lm	90 lm/W
82W	ECLIPSE-A-176-830-82	3000K	80	12,430 lm	80 lm/W
82W	ECLIPSE-A-176-840-82	4000K	80	13,002 lm	80 lm/W
82W	ECLIPSE-A-176-930-82	3000K	90	10,780 lm	90 lm/W
82W	ECLIPSE-A-176-940-82	4000K	90	11,253 lm	90 lm/W
74W	ECLIPSE-A-192-830-74	3000K	80	11,352 lm	80 lm/W
74W	ECLIPSE-A-192-840-74	4000K	80	11,880 lm	80 lm/W
74W	ECLIPSE-A-192-930-74	3000K	90	9,852 lm	90 lm/W
74W	ECLIPSE-A-192-940-74	4000K	90	10,284 lm	90 lm/W
90W	ECLIPSE-A-192-830-90	3000K	80	13,560 lm	80 lm/W
90W	ECLIPSE-A-192-840-90	4000K	80	14,184 lm	80 lm/W
90W	ECLIPSE-A-192-930-90	3000K	90	11,760 lm	90 lm/W
90W	ECLIPSE-A-192-940-90	4000K	90	12,276 lm	90 lm/W
80W	ECLIPSE-A-208-830-80	3000K	80	12,298 lm	80 lm/W
80W	ECLIPSE-A-208-840-80	4000K	80	12,870 lm	80 lm/W
80W	ECLIPSE-A-208-930-80	3000K	90	10,673 lm	90 lm/W
80W	ECLIPSE-A-208-940-80	4000K	90	11,141 lm	90 lm/W
97W	ECLIPSE-A-208-830-97	3000K	80	14,690 lm	80 lm/W
97W	ECLIPSE-A-208-840-97	4000K	80	15,366 lm	80 lm/W
97W	ECLIPSE-A-208-930-97	3000K	90	12,740 lm	90 lm/W
97W	ECLIPSE-A-208-940-97	4000K	90	13,299 lm	90 lm/W
86W	ECLIPSE-A-223-830-86	3000K	80	13,244 lm	80 lm/W
86W	ECLIPSE-A-223-840-86	4000K	80	13,860 lm	80 lm/W
86W	ECLIPSE-A-223-930-86	3000K	90	11,494 lm	90 lm/W
86W	ECLIPSE-A-223-940-86	4000K	90	11,998 lm	90 lm/W
105W	ECLIPSE-A-223-830-105	3000K	80	15,820 lm	80 lm/W
105W	ECLIPSE-A-223-840-105	4000K	80	16,548 lm	80 lm/W
105W	ECLIPSE-A-223-930-105	3000K	90	13,720 lm	90 lm/W
105W	ECLIPSE-A-223-940-105	4000K	90	14,322 lm	90 lm/W
93W	ECLIPSE-A-240-830-93	3000K	80	14,190 lm	80 lm/W
93W	ECLIPSE-A-240-840-93	4000K	80	14,850 lm	80 lm/W
93W	ECLIPSE-A-240-930-93	3000K	90	12,315 lm	90 lm/W
93W	ECLIPSE-A-240-940-93	4000K	90	12,855 lm	90 lm/W
113W	ECLIPSE-A-240-830-113	3000K	80	16,950 lm	80 lm/W
113W	ECLIPSE-A-240-840-113	4000K	80	17,730 lm	80 lm/W
113W	ECLIPSE-A-240-930-113	3000K	90	14,700 lm	90 lm/W
113W	ECLIPSE-A-240-940-113	4000K	90	15,345 lm	90 lm/W
98W	ECLIPSE-A-255-830-98	3000K	80	15,136 lm	80 lm/W
98W	ECLIPSE-A-255-840-98	4000K	80	15,840 lm	80 lm/W
98W	ECLIPSE-A-255-930-98	3000K	90	13,136 lm	90 lm/W
98W	ECLIPSE-A-255-940-98	4000K	90	13,712 lm	90 lm/W
120W	ECLIPSE-A-255-830-120	3000K	80	18,080 lm	80 lm/W
120W	ECLIPSE-A-255-840-120	4000K	80	18,912 lm	80 lm/W
120W	ECLIPSE-A-255-930-120	3000K	90	15,680 lm	90 lm/W
120W	ECLIPSE-A-255-940-120	4000K	90	16,368 lm	90 lm/W
105W	ECLIPSE-A-271-830-105	3000K	80	16,082 lm	80 lm/W
105W	ECLIPSE-A-271-840-105	4000K	80	16,830 lm	80 lm/W
105W	ECLIPSE-A-271-930-105	3000K	90	13,957 lm	90 lm/W
105W	ECLIPSE-A-271-940-105	4000K	90	14,569 lm	90 lm/W
127W	ECLIPSE-A-271-830-127	3000K	80	19,210 lm	80 lm/W
127W	ECLIPSE-A-271-840-127	4000K	80	20,094 lm	80 lm/W
127W	ECLIPSE-A-271-930-127	3000K	90	16,660 lm	90 lm/W
127W	ECLIPSE-A-271-940-127	4000K	90	17,391 lm	90 lm/W
111W	ECLIPSE-A-287-830-111	3000K	80	17,028 lm	80 lm/W
111W	ECLIPSE-A-287-840-111	4000K	80	17,820 lm	80 lm/W
111W	ECLIPSE-A-287-930-111	3000K	90	14,778 lm	90 lm/W
111W	ECLIPSE-A-287-940-111	4000K	90	15,426 lm	90 lm/W
135W	ECLIPSE-A-287-830-135	3000K	80	20,340 lm	80 lm/W
135W	ECLIPSE-A-287-840-135	4000K	80	21,276 lm	80 lm/W
135W	ECLIPSE-A-287-930-135	3000K	90	17,640 lm	90 lm/W
135W	ECLIPSE-A-287-940-135	4000K	90	18,414 lm	90 lm/W
